Product Information HOME > Product Information > EXPLOSION BOND & OVERLAY WELDED PRODUCTS > EXPLOSION BOND PRODUCTS
Select product name :
EXPLOSION BOND PRODUCTS

Explosive Welding is made with a solid-state welding process that uses controlled explosive to join two or more otherwise incompatibel and exotic materials at the molecular level. This in a permanent, solder-free metallurgical bond, and can create composites that are lightweig have superior stength.

Plates are accerlerated into one another with the forces generated by an explosive detonation. The "Flyer" plate yields to the force of the explosion as the detonation front moves acress the surface of the plate. Forces at the collision point cause the first few atomic layers of each surface to become plasma. This leading plesma jet effectively scrubs both surfaces as the collision point accelerates acress the plates creating a full metallurgical weld. Explosive metal bonding is considered a cold joining process because the materials remain at or near ambient temperature and retain orginal characteristics.

Using technology that Raremetal korea developed, we can provide Titanium explosive bond clad. It's possible to weld almost all kinds of base materials as the above figure.

No Data.
